中蓝泵业
                                                                                                                                                                                                                中蓝泵业
                天津            有限责任公司                                                                                                                                                                       天津            有限责任公司
                          TIANJIN ZHONGLAN PUMP CO., LTD.                                                                                                                                                             TIANJIN ZHONGLAN PUMP CO., LTD.

            ●故障报警画面   Failure alarm screen
                                                                                                                                     16.           预制泵站控制系统   Prefabricated pump station control system
                                                                                  故障发生时,所有画面左上角闪
                                                                              烁显示     ,页面滚动文字显示故障信                                   ◎专门为排水泵站设计的完整的控制系统,满足功能的拓展需要,
                                                                              息,控制柜故障指示灯亮、蜂呜器呜响。                                       并有可靠的支持。
                                                                              同时,3G 通信模块自动发送故障信息                                     ◎集约化的设计,从此告别人员值守。
                                                                              到管理人员手机上。
                                                                                                                                     ◎智能化的远程控制,运行尽在掌握之中。
                                                                              When the fault occurs. all the upper                   ◎控制柜采用户外型设计,可安装在泵站顶部,也可以独立安装
                                                                              left corner of the screen flashing                       地面上。
                                                                              display    ,  page  scrolling  text                    ◎完整的、即插即用的控制柜。
                                                                              display fault informatian. control
                                                                              cabinet fault indicator light, buzzer                  ◎起停液位的设置,一台潜水泵必须设置 2 个液位使用,2 台潜
                                                                              ringing. At the same time. the 3G                        水泵至少设置 3 个液位使用。
                                                                              communication module sends the                         ◎ For the drainage pump station design of complete
                                                                              fault information to the manager's                       Control system, to meet the needs of the expansion of
                                                                              mobile phone automatically.                              functions.And reliable support.
                                                                                                                                     ◎ Intensive design, no need human on site.
            ●设备 IO 点状态   Device IO point status                                                                                      ◎ Intelligent remote control. the operation is under control.
                                                                                                                                     ◎ The control cabinet adopts outdoor design. which can
                                                                                  此画面显示 PLC 的 IO 状态,可                                  be installed on the top of the pump station. and also can
                                                                              帮助调试设备和故障排除。                                             be installed independently on the ground.
                                                                              This screen displays the lO state                      ◎ Integrated plug and play control cabinet.
                                                                              of the PLC. which helps debug the                      ◎ Starting and stopping level setting,one submersible pump must be set to use 2 liquid levels, and two
                                                                              device and troubleshoot.                                 submersible pumps must be set to use at least 3 liquid levels.
                                                                                                                                   ●关键功能特点 Key Functional Characteristics

                                                                                                                                     ◎ 304 不锈钢,户外型、防雨、防尘、防盗                            ◎ When the liquid level is too high. the pump
                                                                                                                                     ◎水泵的自动并联控制                                          starts in parallel to quickly drain water.
                                                                                                                                     ◎手动操作运行                                           ◎ Set the start and stop level at will.
                                                                                                                                     ◎水泵启停自动控制                                         ◎ It can show the flow rate of pump station and
                                                                                                                                     ◎当液位过高时,水泵并联启动快速排水                                  the displacement of pump.
                                                                                                                                     ◎任意设置启停液位                                         ◎ Set up regular emptying function to prevent

            ●地图定位功能   Map positioning function                                                                                       ◎可显示泵站的入流量以及水泵排水量                                   silt blockage.
                                                                                                                                     ◎设定定时清空功能,防止淤泥堵塞                                  ◎ Allocate the running time of each pump
                                                                                                                                     ◎定时轮换功能,在多泵控制中,科学分配每台水泵                             scientifically.
                                                                                                                                       的运行时间                                           ◎ Lightning protection.
                                                                                                                                     ◎防雷击保护功能                                          ◎ Adding UPS uninterruptible power supply
                                                                                                                                     ◎增加 UPS 不间断电源接口                                     interface.
                                                                                                                                     ◎远程监控:外部 RS485 接口,GPRS/GSM 无线                     ◎ Remote monitoring: external RS485 interface.
                                                                                                                                       远程通讯功能并提供配套物联网远程监控平台,实                            GPRS/GSM wireless Remote communication
                                                                                                                                       现对泵站的监视功能                                         function. and provide a supporting IOT remote
                                                                                                                                     ◎人性化的人机操作界面,简易、便捷                                   monitoring platform. to achieve the monitoring
                                                                                                                                     ◎系统结构图形直观显示,可从系统图中直接显示出                             function of the pump station.
                                                                                                                                       各泵运行故障情况及转速、泵站液位可读                              ◎ User-friendly man-machine interface, Simple
                                                                                                                                                                                         and convenient.
                                                                                                                                     ◎ Stainless steel 304. outdoor type. rainproof.   ◎ The system structure diagram is visually
                                                                                                                                       dustproof. burglarproof.                          displayed. which can directly display the pump
                                                                                                                                     ◎ Automatic parallel control of water pump.         fault and speed. and the pump level can be
                                                                                                                                     ◎ Manual operation.                                 read from the system diagram.
                                                                                                                                     ◎ Automatic control of starting and stopping of
                                                                                                                                       water pump.
